ROTOR DISC » RN1233V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
4
Height
46.2
Centering Diameter
59
Pitch Circle Ø
100
Front/Rear
Front
Outter Ø
238
Drum Ø:
130

Cross Reference

NISSAN
40206-1F500
NISSAN
40206-72B00
SUZUKI
40206-72B01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.92~11.99 1000 CG10DE K11 JPN RN1581VRN1233V PN2435PN2226PN2131 FN1204
01.92~11.99 1300 CG13DE HK11 RN2021VRN1233V PN2131PN2226 PN2277FN1204
08.92~12.02 1000 CG10DE K11E RN1233VRN1043 PN2191 DN1318 PN2210FN1251
07.00~12.02 1300 CGA3DE K11E RN1233VRN1043 PN2191 DN1318 FN1251
02.98~12.02 1500 TD15 K11E RN1233VRN1043 PN2191 DN1318 FN1251

Exemption from liability: the catalog data is advisory and can be used for reference only
