ROTOR DISC » RN1175

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
4
Height
61
Centering Diameter
76
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
262
Drum Ø:
168
Disc Thickness (Min)
8.4
Structure Material
G3000

Cross Reference

HYUNDAI
58411-38310
HYUNDAI
5841138300
KIA
584113C000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.98~02.01 2000 G4JP EF RN1230V PN2245PN0377 RN1175DN1449 FN0612PN0539 FN0661
02.01~06.06 2000 G4JP EF RN1230V PN0377PN2245 RN1175 PN0539PN0436 FN0661
03.98~02.01 2500 G6BV EF RN1230V PN2245 RN1175 PN0539
02.01~04.05 2700 G6BA PA02 US RN1231V PN0377 RN1175 PN0539 FN0661

Exemption from liability: the catalog data is advisory and can be used for reference only
