ROTOR DISC » RN2838V

Image Not Available

Specification

Type
Vented
Outter Ø
323
Num. of holes
5
Hole Ø:
16
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
49.5
Centering Diameter
66
Pitch Circle Ø
120
Drum Ø:
160
Front/Rear
Front
Structure Material
G3000

Cross Reference

BYD
13541759-00
BYD
SA3HA-3501011A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

BYD   »   Song Plus

06.23~ TZ200XYM SA3EDA RN2838V PN6103 RN2840RN2839 PN6098
03.21~07.24 1500 BYD472QA RN2841VRN2838V PN8001PN6097 RN2839RN2840 PN6098
07.24~ 1500 BYD472QC SA3HDA RN2838V PN6097 RN2840 PN6098
