ROTOR DISC » RN2754V

RN2754V

Specification

Type
Vented
Outter Ø
298
Num. of holes
5
Hole Ø:
13
Disc Thickness (Max)
26
Disc Thickness (Min)
24
Height
47
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Structure Material
G3000
Drum Ø:
150

Cross Reference

BYD
13188254-00
BYD
13781672-00
BYD
15538157-00
BYD
16782103-00
BYD
HA2EL-3501111
BYD
HA2EL-3501111A
BYD
HA2EL-3501111AS-D1
BYD
HA2EL-3501111BS
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

BYD   »   Atto 2

03.24~ TZ200XSW SC3E RN2754V PN6085 PN6098
11.25~ 1500 BYD472QA SC3HBU RN2754V PN6085 PN6098

BYD   »   Atto 3

02.22~ TZ200XSQ SC2E RN2754V PN6085 RN2836 PN6098

BYD   »   Chazor

03.23~ 1500 BYD472QA HA2HGU RN2754V PN6085 RN2837 PN6098

BYD   »   Destroyer 05

02.24~ 1500 BYD472QA HA2H RN2754V PN6085 RN2837 PN6098

BYD   »   Qin Plus

03.21~02.25 1500 BYD472QA HA2H RN2754V PN6085 RN2837 PN6098
02.25~ 1500 BYD472QC HA5HA RN2754V PN6085 PN6098

BYD   »   Seal 05

02.25~ 1500 BYD472QC HA6H RN2754V PN6085 PN6098

BYD   »   Yuan Plus

02.22~ TZ200XSQ SC2E RN2754V PN6085 RN2836 PN6098

BYD   »   Yuan Up

03.24~ TZ200XSW SC3E RN2754V PN6085 PN6098
