ROTOR DISC » RN2713

RN2713

Specification

Type
Solid
Outter Ø
269
Num. of holes
5
Hole Ø:
14.6
Disc Thickness (Max)
12
Disc Thickness (Min)
10.5
Height
64.9
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
170
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HI-Q
SD4051
TOYOTA
42431-06050
TOYOTA
42431-06051
TOYOTA
42431-33100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   ES330

07.03~03.06 3300 3MZ-FE MCV31 RN1162V PN1480PN1479 RN2713 PN1458 FN0633

TOYOTA   »   Avalon

01.05~07.07 3500 2GR-FE GSX30L RN1162VRN1241V PN1480PN1521 RN2713RN1432 PN1522PN0427 FN0633

TOYOTA   »   Camry

08.01~01.06 2000 1AZ-FE ACV31L RN1009V PN1479 RN1223RN2713 PN1458 FN0633
08.01~11.06 2400 2AZ-FE ACV30L RN1009V PN1479 DN1212RN2713 FN2333PN1458FN2406 FN0633
09.01~01.06 2400 2AZ-FE ACV30R RN1009V PN1479 RN2713 PN1458 FN0633
09.03~02.06 3300 3MZ-FE MCV31L RN1162V PN1479 RN2713 PN1458

TOYOTA   »   Solara coupe (USA)

07.03~08.08 2400 2AZ-FE ACV30L RN1162V PN1480 RN2713 PN0427 FN0633
07.03~12.08 3300 3MZ-FE MCV31L RN1162V PN1480PN1479 RN2713 PN0427PN1458 FN0633

TOYOTA   »   Windom

07.01~02.06 3000 1MZ-FE MCV30 RN1162V PN1479PN1480 RN2713 PN1458
