ROTOR DISC » RN2116V

Specification

Type
Vented
Outter Ø
249
Num. of holes
4
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
46.3
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
130
Front/Rear
Front
Structure Material
G3000

Cross Reference

PERODUA
43512BZ160000
TOYOTA
43512BZ160
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.09~ 1500 3SZ-VE M502 RN2116V PN1508 FN2389

Exemption from liability: the catalog data is advisory and can be used for reference only
