ROTOR DISC » RN2664V

RN2664V

Specification

Type
Vented
Outter Ø
286
Num. of holes
5
Hole Ø:
12.7
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
49.5
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
143
Front/Rear
Front
Structure Material
G3000

Cross Reference

CHANGAN
3501101-M01
CHANGAN
3501101-M01-AB
CHANGAN
3501101-M04
CHANGAN
S301066-0200-AB
CHANGAN
S301066-0210
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   CS75

01.14~ 1800 JL486ZQ2 SC6469 RN2664V PN8802 RN2665 PN6016

CHANGAN   »   CS75 Plus

09.19~ 1500 JL476ZQCF SC6479 RN2664V PN8802PN8029 RN2665 PN8025
Copyright © 2003-2025 JNBK Corporation. All Rights Reserved

Exemption from liability: the catalog data is advisory and can be used for reference only
