ROTOR DISC » RN2057V

Specification

Type
Vented
Outter Ø
307
Num. of holes
5
Disc Thickness (Max)
24
Height
45
Centering Diameter
67
Pitch Circle Ø
112
Drum Ø:
151
Disc Thickness (Min)
22.4
Structure Material
G3000

Cross Reference

BMW
34 10 6 891 079
BMW
34 11 6 799 351
BMW
34 11 6 860 957
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.19~ 1500 B38A15A F40 RN2057V PN0577PN0573 RN2058 PN0651
06.19~ 1500 B38A15A F40 RN2057V PN0577 RN2058 PN0651
10.19~03.23 1500 B38A15A AN04 SG RN2057V PN0577PN0573 RN2058 PN0651
11.21~ 1500 B38A15P U06 RN2057V PN32011 RN2058 PN32010
07.20~ 2000 B47C20B F44 RN2057V PN0577PN0672 RN2058RN1764V PN0651
11.18~12.22 1500 B38A15 F46 RN2057V PN0573PN0577 RN2058 PN0651
03.15~03.18 1500 B38A15A F46 RN2057V PN0577 RN2058 PN0651
11.21~ 1500 B38A15 U06 RN2057V PN32011 RN2058 PN32010
07.14~06.16 1500 B38A15A F45 RN2407VRN2057V PN0577PN0573 RN2058 PN0651
10.19~03.23 1500 B38A15A AK0 RHD RN2057V PN0672PN0577PN0573 RN1764VRN2058 PN0651
11.14~10.21 2000 B47C20A F45 RN2057V PN0577 RN2058 PN0651
11.14~10.21 2000 B48A20 F45 RN2057V PN0577 RN2058 PN0651
07.22~ 1500 B38A15P U06 RN2057V PN32011 RN1764V PN32010
11.15~06.16 1600 B37C15A F48 RN2407VRN2057V PN0577PN0573 RN2058 PN0651
07.15~06.22 2000 B47C20A F48 RN2057V PN0577 RN2058 PN0651
07.22~ 2000 B47C20B U11 RN2057V PN32011 RN2058 PN32010
11.15~06.22 1500 B38A15A F48 RN2057V PN0577 RN2058 PN0651
07.17~06.22 1500 B38A15A F48 RN2057V PN0577 RN2058 PN0651
07.15~06.22 2000 B47C20A F48 RN2057V PN0573PN0577 RN2058 PN0651
10.19~02.23 2000 B47C20B 32AD JPN RHD RN2057V PN0577PN0573 RN2058 PN0651
11.22~ 2000 B47C20B U11 RN2057VRN2062V PN32012PN32011 RN1764V PN32010
03.18~ 1500 B32S15A F39 RN2057V PN0573PN0577 RN2058 PN0651
03.18~ 1500 B38A15A F39 RN2057V PN0573PN0577 RN2058 PN0651
11.17~06.20 2000 B47C20A F39 RN2057V PN0672PN0577 RN1764VRN2058 PN0651
11.17~ 2000 B47C20B F39 RN2057V PN0577PN0672 RN2058RN1764V PN0651
10.16~ 1500 B36A15A F60 RN2057V PN0573PN0577 RN2058 PN0651
01.15~ 2000 B46A20A F54 RN2057V PN0577PN0573 RN2058 PN0651

Exemption from liability: the catalog data is advisory and can be used for reference only
