NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2051V

Product
Application

ROTOR DISC » RN2051V

Specification

Type

Vented

Outter Ø

267.6

Num. of holes

6

Disc Thickness (Max)

28

Height

28

Centering Diameter

93

Pitch Circle Ø

116

Structure Material

G3000

Front/Rear

Front

Cross Reference

MAZDA

S49K-33-25X

MITSUBISHI

MQ905217

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MAZDA » Bongo Brawny

11.04~08.10	2000	RF-T	SKF6V	RN2051V	PN5376		FN3426 FN3425
06.99~11.04	2500	WL	SK56M	RN2051V	PN5376		FN3407 FN3406
06.99~11.04	2500	WL	SK56V	RN2051V	PN5376		FN3407 FN3406

MAZDA » Titan

10.00~08.10	2000	FE	SYE4T	RN2051V	PN5376 PN3414		FN3406 FN3426 FN3407 FN3425
10.00~08.10	2000	FE	SYE6T	RN2051V	PN5376		FN3407
08.04~08.07	2000	RF-T	SYF6L	RN2051V	PN5376		FN3425 FN3426
08.04~09.07	2000	RF-T	SYF6T	RN2051V	PN5376		FN3426 FN3425
10.00~01.05	2500	WL	SY56L	RN2051V	PN5376		FN3406 FN3407
10.00~01.05	2500	WL	SY56T	RN2051V	PN5376		FN3407 FN3406
