ROTOR DISC » RN2015V

Specification

Type
Vented
Outter Ø
227
Num. of holes
4
Disc Thickness (Max)
17
Height
49.2
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Front/Rear
Front
Structure Material
G3000

Cross Reference

MAZDA
1A10-33-251A
NISSAN
40206-4A00E
SUZUKI
55311-75F20
SUZUKI
55311-75F21
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.09~03.13 660 K6A# ML21S RN2015V PN9523 FN9967
11.06~01.11 660 K6A# HG21S RN2015VRN1985 PN9523 FN9967
01.08~03.13 660 K6A# MK21S RN2015V PN9523 FN9967
01.07~10.08 660 K6A# MH22S RN1985RN2015V PN9523 FN9967

Exemption from liability: the catalog data is advisory and can be used for reference only
