NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2012V

Product
Application

ROTOR DISC » RN2012V

Specification

Type

Vented

Outter Ø

231

Num. of holes

4

Hole Ø:

13.1

Disc Thickness (Max)

17

Height

49.4

Centering Diameter

60

Pitch Circle Ø

100

Drum Ø:

125.8

Front/Rear

Front

Structure Material

G3000

Disc Thickness (Min)

15

Cross Reference

SUBARU

26300-KG000

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUBARU » R1

11.04~03.10	660	EN07	RJ1	RN2012V	PN9426		FN9967
11.04~04.10	660	EN07	RJ2	RN2012V	PN9426		FN9967

SUBARU » R2

10.03~04.10	660	EN07	RC1	RN2012V	PN9426		FN9967
10.03~04.10	660	EN07#	RC2	RN2012V	PN9426		FN9967

SUBARU » Stella

06.06~03.11	660	EN07	RN2	RN2012V	PN9426		FN9967
06.06~03.11	660	EN07#	RN1	RN2012V	PN9426		FN9967
