ROTOR DISC » RN2009V

RN2009V

Specification

Type
Vented
Outter Ø
221
Num. of holes
4
Disc Thickness (Max)
18
Height
50.2
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Drum Ø:
125.5

Cross Reference

SUBARU
26311TA001
SUBARU
26311TA002
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUBARU   »   Sambar

03.90~12.98 660 EN07 KV4 RN2009V PN7251 FN7750
03.90~12.98 660 EN07# KS4 RN2009V PN7251 FN7750FN7743
03.90~12.98 660 EN07# KV3 RN2009V PN7251 FN7750FN7743
11.89~12.98 660 EN07C KS3 RN2009V PN7251 FN7743FN7750
