NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2008V

Product
Application

ROTOR DISC » RN2008V

Specification

Type

Vented

Outter Ø

314

Num. of holes

5

Disc Thickness (Max)

18

Height

71.5

Centering Diameter

69

Pitch Circle Ø

114.3

Disc Thickness (Min)

16.4

Drum Ø:

190

Structure Material

G3000

Hole Ø:

12.5

Front/Rear

Rear

Cross Reference

HYUNDAI

58411-C5700

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Maxcruz

08.15~11.18

2200

D4HB

DM

RN2279V

PN0446

RN2008V

PN0415

FN0691

KIA » Sorento 15

08.14~01.18	2200	D4HB	PC515 RHD	RN1652V RN1349V	PN0662	RN2008V RN1713	PN0457	FN0754
08.14~01.18	2400	G4KJ	UM	RN1349V	PN0662	RN2008V	PN0457	FN0754

KIA » Sorento 18

07.17~03.20	2200	D4HB	PC518 RHD	RN1349V	PN0662	RN2008V	PN0457	FN0754
07.17~11.20	2400	G4KJ	PC518 LHD	RN1349V	PN0662	RN2008V	PN0457	FN0754
07.17~11.20	3500	G6DC	PC518	RN1349V RN2279V	PN11003 PN0662	RN2008V	PN0457	FN0754
