ROTOR DISC » RN1981V

Specification

Type
Vented
Outter Ø
335
Num. of holes
5
Disc Thickness (Max)
30
Height
60.5
Centering Diameter
62
Pitch Circle Ø
120
Front/Rear
Front
Disc Thickness (Min)
27
Drum Ø:
162
Structure Material
G3000

Cross Reference

TOYOTA
43512-50240
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.20~ 3KM JPD20 RN1981V PN1833 PN1844

Exemption from liability: the catalog data is advisory and can be used for reference only
