ROTOR DISC » RN2633V

RN2633V

Specification

Type
Vented
Outter Ø
300
Num. of holes
6
Hole Ø:
12.6
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
61.1
Centering Diameter
101
Pitch Circle Ø
139.7
Drum Ø:
171
Front/Rear
Front
Structure Material
G3000

Cross Reference

GM
98376752
ISUZU
8-98376-752-0
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   D-Max

09.19~ 1900 RZ4E-TC TFS87 ML RHD RN2633V PN2402PN2401 DN1440 FN6741
07.20~ 3000 4JJ3-TCX TFS40 RHD RN2633VRN2416V PN2401PN2402 DN1440 FN6741

MAZDA   »   BT-50

06.20~ 3000 4JJ3-TCX MP2TFS40 RN2416VRN2633V PN2401PN2402 DN1440 FN6741
