ROTOR DISC » RN2625V

Image Not Available

Specification

Type
Vented
Outter Ø
339
Num. of holes
6
Hole Ø:
13.5
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
56.7
Centering Diameter
108
Pitch Circle Ø
139.7
Drum Ø:
204
Front/Rear
Rear
Structure Material
G3000

Cross Reference

CHANGAN
3502101-BU01
CHANGAN
PC201058-0801
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   Hunter F70

10.19~ 1900 DEV-D20TCIE SC1031 RN2624V PN8023 RN2625V PN6017
09.21~ 2000 GW4D20M SC1031 RN2624V PN8023 RN2625V PN6017

CHANGAN   »   Hunter Plus

10.23~ 2000 JL486ZQ5 SC1031 RN2624V PN8023 RN2625V
