ROTOR DISC » RN2615V

RN2615V

Specification

Type
Vented
Outter Ø
300
Num. of holes
9
Disc Thickness (Max)
25
Height
46.7
Centering Diameter
65
Front/Rear
Front
Structure Material
G3000
Disc Thickness (Min)
23
Pitch Circle Ø
112
Hole Ø:
15
Drum Ø:
142.5

Cross Reference

MG
10282168
MG
11193996
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MG (SAIC)   »   MG 5

11.20~ 1500 15C4E RN2615V PN0348W RN2634 PN33003

MG (SAIC)   »   MG 6

04.18~ 1000 10E4E RN2615V PN0348W RN2634 PN33003
07.20~ 1500 15C4E RN2615V PN0348W RN2634 PN33003
11.17~06.20 1500 15E4E RN2615V PN0348W RN2634 PN33003
04.19~ 1500 15E4E RN2615V PN0348W RN2634 PN33003

MG (SAIC)   »   One

12.21~ 1500 15C4E RN2615V RN2634

MG (SAIC)   »   ZS EV

03.20~ 45 44.5 kWh CV RN2615V PN0348W PN52018
