ROTOR DISC » RN2610V

RN2610V

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Hole Ø:
12.6
Disc Thickness (Max)
30
Disc Thickness (Min)
28.4
Height
56.5
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
155
Front/Rear
Front
Structure Material
G3000

Cross Reference

HYUNDAI
51712-3M700
HYUNDAI
51712-B1100
HYUNDAI
51712-B1600
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GENESIS   »   G80

03.16~12.20 2000 G4KL PB116 RN2610V PN0633 RN2148 PN0649PN0415 FN0758
03.16~12.20 2200 D4HC PB116 RN2610VRN1711V PN0633 RN2148 PN0649PN0415 FN0758
