ROTOR DISC » RN2605V

RN2605V

Specification

Type
Vented
Outter Ø
266
Num. of holes
5
Hole Ø:
13.3
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
48
Centering Diameter
71.1
Pitch Circle Ø
108
Drum Ø:
136.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

Peugeot / Citroen
16 107 046 80
Peugeot / Citroen
16 427 612 80
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

PEUGEOT   »   308

09.13~05.21 1200 EB2DT T9 RN2605V PN42004 RN1862 PN0856
09.13~12.17 1600 DV6FD 5DR HB RN2605VRN2160VRN1896V PN0045PN42004PN0042 RN1862 PN0856PN0044
