ROTOR DISC » RN2602V

Image Not Available

Specification

Type
Vented
Outter Ø
272
Num. of holes
5
Disc Thickness (Max)
23
Disc Thickness (Min)
21
Height
41.5
Centering Diameter
69.1
Pitch Circle Ø
110
Front/Rear
Front
Structure Material
G3000

Cross Reference

CHANGAN
3501101-BE01
CHANGAN
B311055-0500
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   CS15

04.16~ 1500 JL473QF SC7159 RN2602V PN5544 RN2603 PN6030
