ROTOR DISC » RN2590V

RN2590V

Specification

Type
Vented
Outter Ø
268
Num. of holes
6
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
39.5
Centering Diameter
88
Front/Rear
Front
Structure Material
G3000
Pitch Circle Ø
139.7

Cross Reference

GREAT WALL
3103101XP55AB
GREAT WALL
3103101XP55AC
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

Great Wall Motors   »   Wingle 5

10.17~ 2200 GW491QE CC1021PS RN2590V PN6073 FN4467
