ROTOR DISC » RN2588V

Image Not Available

Specification

Type
Vented
Outter Ø
317
Num. of holes
5
Hole Ø:
15.5
Disc Thickness (Max)
18
Disc Thickness (Min)
16.5
Height
44.2
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
162
Front/Rear
Rear
Structure Material
G3000

Cross Reference

TOYOTA
42431-78030
TOYOTA
42431-F6010
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   NX200

01.22~ 2000 M20A-FKS MAZA20 RN1931V PN1845 RN2588V PN1868

LEXUS   »   NX250

11.21~ 2500 A25A-FKS AAZA20L RN1931V PN1845 RN2588V PN1868
11.21~ 2500 A25A-FKS AAZA25 RN1931V PN1845 RN2588V PN1868

LEXUS   »   NX350

11.21~ 2400 T24A-FTS TAZA25 RN1931V PN1845 RN2588V PN1868

LEXUS   »   NX350h

11.21~ 2500 A25A-FXS AAZH20 RN1931V PN1845 RN2588V PN1868
11.21~ 2500 A25A-FXS AAZH25 RN1931V PN1845 RN2588V PN1868

LEXUS   »   NX400h+

11.21~ 2500 A25A-FXS AAZH21 RN1931V PN1845 RN2588V PN1868

LEXUS   »   NX450h+

11.21~ 2500 A25A-FXS AAZH26 RN2417V PN1845PN1869 RN2588V PN1868

LEXUS   »   RZ450E

01.23~ EM XEBM15 RN2417V PN1845 RN2588V PN1868

SUBARU   »   Solterra

03.22~ EM YEAM15 RN2417V PN1845 RN2588V PN1868

TOYOTA   »   BZ4X

03.22~ EM XEAM10 RN2417V PN1845 RN2588V PN1868
03.22~ EM YEAM15 RN2417V PN1845 RN2588V PN1868

TOYOTA   »   Crown

09.22~ 2400 T24A-FTS TZSH35 RN2417V PN1845 RN2588V PN1868
09.22~ 2500 A25A-FXS AZSH35 RN1931V PN1845 RN2588V PN1868
08.23~ 2500 A25A-FXS AZSH36 RN1931V PN1845 RN2588V PN1868

TOYOTA   »   Crown Crossover

09.22~ 2400 T24A-FTS TZSH35 RN2417V PN1845 RN2588V PN1868
09.22~ 2500 A25A-FXS AZSH35 RN1931V PN1845 RN2588V PN1868
