ROTOR DISC » RN2581V

Image Not Available

Specification

Type
Vented
Outter Ø
316
Num. of holes
5
Hole Ø:
13.4
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
43
Centering Diameter
66
Pitch Circle Ø
108
Drum Ø:
139
Front/Rear
Front
Structure Material
G3000

Cross Reference

Chery
204000243AA
Chery
204000354AA
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

EXEED (CHERY)   »   TXL

04.19~ 1600 SQRF4J16A M32T RN2581V PN8802 RN2560 PN8005
08.22~ 2000 SQRF4J20C M32T RN2581V PN8802 RN2560 PN8005

EXEED (CHERY)   »   VX

04.20~ 2000 SQRF4J20C M36T RN2581V PN8802 RN2582 PN8005
