ROTOR DISC » RN2563V

RN2563V

Specification

Type
Vented
Outter Ø
308
Num. of holes
5
Disc Thickness (Max)
33
Disc Thickness (Min)
30
Height
55.3
Centering Diameter
93
Pitch Circle Ø
116
Drum Ø:
136
Front/Rear
Front
Structure Material
G3000
Hole Ø:
M10x1.5

Cross Reference

FORD
2 168 836
FORD
2 171 541
FORD
BK21-1125-EA
FORD
BK21-1125-FA
FORD
CK4Z-1125-E
FORD
CK4Z-1125-F
FORD
CK4Z-1125-J
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FORD   »   Transit

05.19~ 2000 T20DD0J TTS RN2563VRN1752V PN0667W RN2564V PN0660
08.19~ 2200 T22DD0P (125PS) TTG (RUS) RN2563V PN0885WPN0667W RN2564V PN0660

FORD   »   Transit Custom

05.19~ 2000 T20DD0J (Ecoblue F) TTF RN2563V PN0667W RN1843 PN0660
05.19~ 2200 T22DD0P (125PS) TTF RN2563V PN0667W RN1843 PN0660

FORD (USA)   »   Transit

10.19~ 3500 T35PDED TTH RN2563V PN0885WPN51034W PN51018W
