ROTOR DISC » RN2554

RN2554

Specification

Type
Solid
Outter Ø
262
Num. of holes
5
Disc Thickness (Max)
10
Height
47
Centering Diameter
55
Pitch Circle Ø
114.3
Front/Rear
Rear
Structure Material
G3000
Disc Thickness (Min)
8.4

Cross Reference

GEELY
1064001294
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GEELY   »   Emgrand

07.12~11.16 1500 JL4G15 FE-1 RN2552V PN8046PN0537PN0187W RN2554 PN0591PN0069PN0019W
07.12~03.17 1800 JL4G18 FE-1 RN2552VRN2553V PN0537PN0187WPN8046 RN2554 PN0019WPN0069PN0591
