ROTOR DISC » RN2542V

Image Not Available

Specification

Type
Vented
Outter Ø
331
Num. of holes
5
Hole Ø:
13.7
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
49.9
Centering Diameter
70.6
Pitch Circle Ø
114.3
Drum Ø:
141.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

CHANGAN
3501101-CR01
CHANGAN
CD569F260301-0700
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   Uni-K

03.21~ 2000 JL486ZQ5 SC6493 RN2542V PN8026 RN2543 PN8025
