ROTOR DISC » RN2538V

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Disc Thickness (Max)
24
Height
55.6
Centering Diameter
72
Front/Rear
Front
Structure Material
G3000
Hole Ø:
17
Disc Thickness (Min)
22.4
Pitch Circle Ø
127
Drum Ø:
165.3

Cross Reference

CHRYSLER
68273 502AA
CHRYSLER
68273 502AB
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.19~ 3600 ERG JLJL74 RN2538V PN53003 RN2539 PN53007 FN0714

Exemption from liability: the catalog data is advisory and can be used for reference only
