ROTOR DISC » RN2523V

Specification

Type

Vented

Outter Ø

234

Num. of holes

4

Hole Ø:

14

Disc Thickness (Max)

18

Disc Thickness (Min)

16.5

Height

42

Centering Diameter

55

Pitch Circle Ø

100

Drum Ø:

125.3

Front/Rear

Front

Structure Material

G3000

Cross Reference

DAIHATSU

43512-BZ230-001

DAIHATSU

43512-BZ270-001

TOYOTA

43512-BZ230

TOYOTA

43512-BZ270

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

DAIHATSU » Ayla

03.23~	1000	1KR-VE	A350RS	RN2523V	PN6427
03.23~	1200	WA-VE	A351RS	RN2523V	PN6427

TOYOTA » Agya/Wigo

12.12~04.17	1000	1KR-DE	B100LA	RN2523V	PN6427	DN1122	FN2112
12.12~04.17	1000	1KR-DE	B100RA	RN2523V	PN6427	DN1122	FN2112
03.23~	1000	1KR-VE	A350	RN2523V	PN6427
04.17~	1000	1KR-VE	B100	RN2523V	PN6427	DN1122	FN2112
04.17~	1200	3NR-VE	B101L	RN2523V	PN6427		FN2112
03.23~	1200	WA-VE	A351	RN2523V	PN6427
