ROTOR DISC » RN2509V

RN2509V

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Hole Ø:
13.3
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
48
Centering Diameter
71.1
Pitch Circle Ø
108
Drum Ø:
138
Front/Rear
Front
Structure Material
G3000

Cross Reference

Peugeot / Citroen
98 046 057 80
Peugeot / Citroen
98 183 816 80
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CITROEN   »   C5 X

09.21~ 1600 EP6FADTXD ND5GFP RN2509V PN0716 RN1895 PN0043PN0044

PEUGEOT   »   308 SW

06.14~05.21 2000 DW10FC ESTATE LHD RN2509V PN0716 RN1895 PN0043

PEUGEOT   »   408

07.22~ 1200 EP2ADTS 5DR SUV RN2160VRN2509V PN0716PN42005 RN2043RN1895 PN0044PN0043
07.22~ 1600 EP6FADTXHP 5DR SUV RN2160VRN2509V PN0716PN42005 RN1895RN2043 PN0044PN0043

PEUGEOT   »   508

06.20~ 1200 EB2ADT R8 RN2509VRN2160V PN0045PN42005PN0716 RN2043RN1895 PN0044PN0043
03.18~ 1500 DV5RC R8 RN2509VRN2160V PN0716PN0045PN42005 RN1895RN2043 PN0043PN0044
03.18~ 1600 EP6F# R8 RN2160VRN2509V PN0716PN0045PN42005 RN1895RN2043 PN0043PN0044
03.18~ 1600 EP6FADTXD 180 F35GFT RHD 5DR HB RN2160VRN2509V PN0045PN0716 RN1895RN2043 PN0043PN0044
03.18~ 2000 DW10FC R8 RN2160VRN2509V PN0716PN0045PN42005 RN1895RN2043 PN0044PN0043

PEUGEOT   »   508 SW

10.18~ 1500 DV5RC FC WGN EU LHD RN2509VRN2160V PN0045PN42005PN0716 RN1895RN2043 PN0043PN0044
