NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1941

Product
Application

ROTOR DISC » RN1941

Specification

Type

Solid

Outter Ø

290

Num. of holes

5

Disc Thickness (Max)

12

Height

53.2

Centering Diameter

62

Pitch Circle Ø

114.3

Drum Ø:

180

Front/Rear

Rear

Disc Thickness (Min)

10.5

Structure Material

G3000

Hole Ø:

14.5

Cross Reference

TOYOTA

42431-47050

TOYOTA

42431-47080

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Mirai

06.15~05.20		4JM	JDP10L	RN1241V	PN1530	RN1941	PN1846	FN0712
06.15~05.20		4JM	JPD10	RN1241V	PN1530	RN1941	PN1846	FN0712

TOYOTA » Prius Alpha

03.12~	1800	2ZR-FXE	ZVW40R	RN1241V	PN1530	RN1941	PN1846	FN0712
04.11~	1800	2ZR-FXE	ZVW40W	RN1434V	PN1524	RN1941	PN1846	FN0712
04.11~	1800	2ZR-FXE	ZVW41W	RN1434V	PN1524	RN1941	PN1846	FN0712

TOYOTA » Prius V

03.12~	1800	2ZR-FXE	ZVW40L	RN1241V	PN1530	RN1941	PN1846	FN0712
03.12~	1800	2ZR-FXE	ZVW40R	RN1241V	PN1530	RN1941	PN1846	FN0712
09.11~11.18	1800	2ZR-FXE	ZVW41L	RN1434V	PN1524	RN1941	PN1846	FN0712
