ROTOR DISC » RN2499V
Specification
Type
Vented
Outter Ø
314
Num. of holes
5
Hole Ø:
16.6
Disc Thickness (Max)
22
Disc Thickness (Min)
18
Height
75.5
Centering Diameter
76
Pitch Circle Ø
120
Drum Ø:
185.1
Front/Rear
Rear
Structure Material
G3000
Cross Reference
VAG
7L6 615 601 E
VAG
7L6 615 601 G
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.03~11.06 | 2500 | BAC | 7LAAA_ | RN1316V | PN0353W | RN2499V | PN0611W | FN0589 |
| 01.06~05.10 | 2500 | BPE | 7L____ | RN1316V | PN0353W | RN2499V | PN0611W | FN0589 |
| 05.04~11.06 | 3200 | BMV | 7LA___ | RN1316VRN1745VRRN1235VLRN1745VSETRN1235VRRN1745VL | PN0346WPN0345WPN0486PN0353W | RN2499VRN1737V | PN0541WPN0611WPN0347W | FN0638FN0589 |
| 05.04~05.06 | 3200 | BRJ | 7LA_G_ | RN1316V | PN0353W | RN2499V | PN0611W |
| 05.03~12.09 | 1900 | AXC | T5 | RN1740VRN1316V | PN0353W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 01.06~12.09 | 1900 | BRR | T5 | RN1740VRN1316V | PN0353W | RN1399VRN2499V | PN0611WPN0330W | FN0589 |
| 05.03~08.15 | 2000 | AXA | T5 | RN1740VRN1316V | PN0353W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 05.10~08.15 | 2000 | CAAE | T5 | RN1316VRN1740V | PN0353W | RN1399VRN2499V | PN0330WPN0611W | FN0589 |
| 05.10~08.15 | 2000 | CCHB | T5 | RN1316VRN1740V | PN0353W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 11.03~12.09 | 2500 | BLJ | T5 | RN1740VRN1316V | PN0353WPN33001W | RN1399VRN2499V | PN0330WPN0611W | FN0589 |
| 05.03~09.15 | 3200 | BDL | T5 | RN1316VRN1740V | PN0353WPN33001W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 05.03~09.15 | 3200 | BKK | T5 | RN1740VRN1316V | PN0353WPN33001W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 05.03~09.15 | 3200 | CFLA | T5 | RN1316VRN1740V | PN33001WPN0353W | RN1399VRN2499V | PN0330WPN0611W | FN0589 |
