ROTOR DISC » RN1918V
Specification
Type
Vented
Outter Ø
355
Num. of holes
5
Disc Thickness (Max)
32
Height
48
Centering Diameter
71
Pitch Circle Ø
108
Front/Rear
Front
Disc Thickness (Min)
30
Drum Ø:
161
Structure Material
G3000
Cross Reference
JAGUAR
C2C 25337
JAGUAR
T2R 5939
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.13~08.17 | 3000 | AJ126 | X150 | RN1918V | PN0678PN0683W | PN0721PN0723 | ||
| 08.13~08.17 | 3000 | AJ126S | X150 | RN1918V | PN0683W | PN0721PN0723 |
| 01.11~05.15 | 2000 | 204PT | X250 | RN1918VRN1916V | PN0462WPN0683W | RN1917V | PN2702 | |
| 01.08~05.11 | 3000 | 306DT | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 06.11~05.15 | 3000 | 306DT | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 03.11~05.15 | 3000 | AJ126 | X250 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 03.08~04.15 | 5000 | AJ133/508PN | CC9 | RN1918V | PN0683W | RN1917V | PN2702 |
| 01.15~ | 2000 | 4PT | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 07.09~ | 3000 | 306DT | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 01.11~12.15 | 3000 | AJ126 | X351 | RN1918V | PN0683W | RN1917V | PN2702 | |
| 01.15~12.19 | 3000 | AJ126 | X351 | RN1918V | PN0683W | PN0721 | ||
| 10.09~08.19 | 5000 | AJ133/508PN | X351 | RN1918V | PN0683W | RN1917V | PN2702 |
| 05.12~08.17 | 2000 | 204PT | X351 | RN1918V | PN0683W | RN1917V | PN2702PN0721 | |
| 05.12~ | 3000 | AJ126 | X351 | RN1918V | PN0683W | RN1917V | PN2702 |
