BRAKE SHOE » FN9970

Specification

Radius
127
Width
41.5
Thickness
4.6
Pcs In Set
4

Cross Reference

BENDIX AUS
BS1861
FMSI
S921-1623
KASHIYAMA
K9970
SUZUKI
53200-65J00
SUZUKI
53200-65J01
SUZUKI
53200-65J02
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.06~04.07 1600 M16A TA74W RN1371V PN9802 FN9970
05.05~06.08 2000 J20A TD54W RN1371V PN9802 FN9970
05.05~06.08 2700 H27A TD94W PN9802 FN9970
04.05~08.12 1600 M16A JB416X-1/2 RN1371V PN9802 DN1406 FN9970
08.08~08.12 1600 M16A JB416X-4/5 RN1371V PN9802 DN1406 FN9970
08.12~07.16 1600 M16A JB416X-7 RN1371V PN9802 DN1406 FN9970
09.05~08.08 2000 J20A JB420W-2 RN1371V PN9802 DN1406 FN9970
06.05~07.16 2000 J20A JTD54V RN1371V PN9802 DN1406 FN9970
01.06~01.14 2000 J20A JTE54V RN1371V PN9802 DN1406 FN9970
01.05~12.15 2000 J20A TD54V RN1371V PN9802 DN1406 FN9970
06.01~09.08 2700 H27A JTD94V RN1371V PN9802 DN1406 FN9970
09.05~01.09 2700 H27A TE94 RN1371V PN9802 DN1406 FN9970

Exemption from liability: the catalog data is advisory and can be used for reference only
