NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1800

Product
Application

ROTOR DISC » RN1800

Specification

Type

Solid

Outter Ø

240

Num. of holes

4

Disc Thickness (Max)

10

Height

42

Centering Diameter

57

Pitch Circle Ø

100

Drum Ø:

141

Disc Thickness (Min)

8.0

Hole Ø:

14.2

Front/Rear

Rear

Structure Material

G3000

Cross Reference

BENDIX

562071B

GM

9117771

GM

9196587

OEM

569108

OEM

569111

OEM

90498304

OPEL

05 69 111

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

OPEL » Astra G

02.98~01.05	1400	Z14XEP	T98	RN1110V	PN0189	RN1800	PN0162
02.98~12.00	1600	X16SZR	F07	RN1110V	PN0189	RN1800	PN0329 FN0599
02.98~12.01	1600	X16XEL	F35	RN1110V	PN0189	RN1800 DN1856	PN0329 FN0599
02.98~01.05	1600	X16XEP	F67 CABRIO RHD	RN1110V	PN0189	RN1800	PN0329
09.98~12.04	1600	Z16XE	T98	RN1110V	PN0189	RN1800	PN0329

OPEL » Astra H

03.04~12.14	1400	Z14XEP	A04	RN1202V	PN0355	DN1593 RN1800	FN0599 PN0329 FN0782
03.04~12.14	1600	Z16XEP	A04	RN1202V	PN0355	DN1593 RN1800	FN0782 FN0599 PN0329
09.04~01.15	2000	Z20LEL	L08	RN1392V	PN0355	RN1800
