ROTOR DISC » RN2482

Specification

Type
Solid
Outter Ø
278
Num. of holes
5
Hole Ø:
15.7
Disc Thickness (Max)
12
Disc Thickness (Min)
10.4
Height
33.5
Centering Diameter
70
Pitch Circle Ø
110
Drum Ø:
137.3
Front/Rear
Rear
Structure Material
G3000

Cross Reference

CHRYSLER
04779 885AB
CHRYSLER
04779 885AC
CHRYSLER
2AMV9885AC
CHRYSLER
68242 659AA
CHRYSLER
68242 659AB
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.14~05.17 2400 RN1870V PN25000 RN2482 PN0849
05.14~05.17 3600 ERB RN1754V PN25000 RN2482 PN0849
09.18~ 2400 EDE KL RN1754V PN25000 RN2482 PN0849

Exemption from liability: the catalog data is advisory and can be used for reference only
