ROTOR DISC » RN2479V

Specification

Type
Vented
Outter Ø
330
Num. of holes
8
Hole Ø:
16.5
Disc Thickness (Max)
29
Disc Thickness (Min)
27
Height
92.5
Centering Diameter
123
Pitch Circle Ø
165.1
Drum Ø:
206
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GM
15712803
GM
19175101
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.02~01.07 6600 LB7 TK25# PN0409 RN2479V PN0055 FN0803
01.02~01.07 6600 LBZ CK257 PN0409 RN2479V PN0055 FN0803
09.10~08.13 6000 L96 K20906 RN2478V PN0409 RN2479V PN0055 FN0803
09.99~08.06 6000 LQ4 TK20906 RN2478V PN0409 RN2479V PN0055 FN0803
09.00~12.07 8100 L18 K29503 PN0409 RN2479V PN0055 FN0803

Exemption from liability: the catalog data is advisory and can be used for reference only
