DRUM BRAKE » DN1121

Specification

Outter Ø
235
Num. of holes
4
Hole Ø
14
Centering Diameter
60
Height
58
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

GM
52071827
GM
52114495
GM
94761125
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.13~08.19 1000 LKL RN2491V PN0627 DN1121 FN0727
01.13~09.18 1400 14SPE4 RN2491V PN0627 DN1121 FN0727

Exemption from liability: the catalog data is advisory and can be used for reference only
