ROTOR DISC » RN2447V

Specification

Type
Vented
Outter Ø
275
Num. of holes
4
Hole Ø:
14
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
41.2
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
132.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

TOYOTA
43512-BZ390
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.21~ 1000 1KR-VET A250A RN2447V PN1871 FN1264
08.21~ 1000 1KR-VET A250L RN2447V PN1871 FN1264
04.21~ 1200 WA-VE A251 RN2447V PN1871 FN1264
08.22~ 1200 3NR-VE NGC100 RN2447V PN0397 PN1865
08.22~ 1300 1NR-VE NGC101 RN2447V PN0397 PN1865
08.22~ 1500 2NR-VE NGC102 RN2447V PN0397 PN1865
08.22~ 1500 2NRVE NGC102L RN2447V PN0397 PN1865

Exemption from liability: the catalog data is advisory and can be used for reference only
