ROTOR DISC » RN2436V

Specification

Type
Vented
Outter Ø
360
Num. of holes
5
Hole Ø:
14.6
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
56.7
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
157
Front/Rear
Front
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
51712-T6200
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.19~ 2500 G4KR JX1 RN2436V PN6133PN6144 RN2437V PN6134
11.19~ 3000 D6JA JX1 RN2436V PN6133PN6144 RN2437V PN6134

Exemption from liability: the catalog data is advisory and can be used for reference only
