ROTOR DISC » RN2434V

RN2434V

Specification

Type
Vented
Outter Ø
239
Num. of holes
4
Hole Ø:
13.3
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
44
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
125
Front/Rear
Front
Structure Material
G3000

Cross Reference

MAZDA
D09H-33-251
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MAZDA   »   Demio

09.14~07.18 1300 P3-VPS DJ3FS RN2434V PN5816 FN3437
