NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2404V

Product
Application

ROTOR DISC » RN2404V

Specification

Type

Vented

Outter Ø

287

Num. of holes

5

Hole Ø:

14

Disc Thickness (Max)

22

Disc Thickness (Min)

21

Height

37.7

Centering Diameter

66.5

Pitch Circle Ø

114.3

Drum Ø:

162.2

Front/Rear

Front

Structure Material

G3000

Cross Reference

DAIHATSU

43512-B4010-000

TOYOTA

43512-B4010

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

DAIHATSU » Bego

01.06~06.16

1500

3SZ-VE

J210G

RN2404V RN1777

PN3285

FN2339

DAIHATSU » Terios

01.06~01.09	1500	3SZ-VE	J210 GL	RN2404V	PN3285	DN1118	FN2339
01.06~11.17	1500	3SZ-VE	J210G	RN1777 RN2404V	PN3285	DN1118	FN2339

TOYOTA » Rush

11.08~06.18	1500	3SZ-VE	J200LE	RN1777 RN2404V	PN3285	DN1118	FN2339
01.06~02.13	1500	3SZ-VE	J210E	RN1777 RN2404V	PN3285		FN2339
05.16~06.18	1500	3SZ-VE	J210LE	RN2404V	PN3285	DN1118	FN2339
