ROTOR DISC » RN2392V

Specification

Type
Vented
Outter Ø
231
Num. of holes
4
Hole Ø:
12.6
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
45
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
126.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

SUZUKI
55311-62R00
SUZUKI
55311-62R00-000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.16~02.20 1200 K12C FH11S LHD RN2392V PN9813 FN9806
01.16~02.20 1200 K12C FH11S RHD RN2392V PN9813 FN9806
09.19~ 1200 K12D ATK412 RN2392V PN9813PN9443 FN9806

Exemption from liability: the catalog data is advisory and can be used for reference only
