ROTOR DISC » RN1662V

RN1662V

Specification

Type
Vented
Outter Ø
345
Num. of holes
6
Disc Thickness (Max)
30
Height
51
Centering Diameter
67.3
Pitch Circle Ø
120
Drum Ø:
159.7
Disc Thickness (Min)
27
Structure Material
G3000

Cross Reference

GM
13501318
GM
19255814
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CADILLAC (GM)   »   SRX

01.09~01.11 2800 LAU RN1662RN1662V PN51006 RN1683V PN51007 FN0753
01.09~04.16 3000 LF1 6NG26 RN1662VRN1662 PN51006 RN1683V PN51007 FN0753
09.11~04.16 3600 LFX 6N1 RN1662RN1662V PN51006 RN1683V PN51007 FN0753
