ROTOR DISC » RN1637V

Specification

Type
Vented
Outter Ø
281
Num. of holes
5
Disc Thickness (Max)
24
Height
45.6
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front

Cross Reference

PROTON
PW828421
PROTON
PW990298
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.09~ 1600 S4PH FZ6 RN1637V PN0543 DN1740 FN71001FN0547
01.12~ 1600 P3-21A RN1637V PN71001 FN71001
01.12~ 1600 Suprima RN1637V PN71001 FN71001

Exemption from liability: the catalog data is advisory and can be used for reference only
