NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1611V

Product
Application

ROTOR DISC » RN1611V

Specification

Type

Vented

Front/Rear

Front

Outter Ø

380

Num. of holes

5

Disc Thickness (Max)

34

Disc Thickness (Min)

31

Height

80.9

Centering Diameter

79

Pitch Circle Ø

120

Drum Ø:

164

Structure Material

G3000

Cross Reference

LAND ROVER

LR 011591

LAND ROVER

LR031845

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

LAND ROVER » Range Rover III

12.09~01.13	4400	448DT / TDV8	L322	RN1611V	PN0567	RN1610V	PN0566	FN0638
01.10~06.12	5000	508PS	LM	RN1611V	PN0567	RN1610V	PN0566	FN0638
