BRAKE SHOE » FN0658
Specification
Radius
84.5
Width
26.5
Thickness
4.5
Pcs In Set
4
Cross Reference
CHEVROLET
96348197
DAEWOO
96496764
FMSI
S888-1602
GM
96496764
SUZUKI
54600-86Z00
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.03~09.06 | 2000 | T20SED | KL1VJ LHD | RN1324V | PN0374 | PN0375 | FN0658 | |
| 06.06~01.12 | 2000 | X20D1 | LA69 GR | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 06.06~01.12 | 2000 | X20D1 | VJ5 GL | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 06.06~01.12 | 2000 | X20D1/LBM | LF69 LHD EU | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 01.07~01.12 | 2000 | Z20S / LLW | LA69 | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 06.04~01.06 | 2500 | LBK | 1VD69 CANADA | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 06.06~01.12 | 2500 | X25D1 | LA69 | RN1323V | PN0380 | RN1325 | PN0375 | FN0658 |
| 06.04~12.12 | 1400 | F14D3 / L14 | J200 | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 01.03~12.12 | 1600 | F16D3 / LXT | J200 | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 01.03~03.13 | 1600 | F16D3 / LXT | JJ83 WGN | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 01.03~03.13 | 1800 | F18D3 | JJ83 WGN | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 11.04~10.11 | 1800 | T18SED | J200 | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 06.04~03.13 | 1800 | T18SED | M48 RHD | RN1324V | PN0374 | RN1391 | PN0376PN0442 | FN0658 |
| 08.03~01.14 | 1400 | F14D3 / L14 | JE48 RHD | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 11.07~01.14 | 1600 | F16D3 / LXT | JJ53 RHD SDN | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
| 01.03~01.14 | 1600 | F16D3 / LXT | NA19 | RN1324V | PN0374 | PN0376PN0442FN12001 | FN0658 | |
| 01.05~01.14 | 1600 | F16D3 / LXT | NA35 | RN1324V | PN0374 | RN1391 | PN0376PN0442FN12001 | FN0658 |
| 08.03~01.14 | 1600 | F16D3 / LXT | NA48 | RN1324V | PN0374 | RN1391 | PN0376PN0442 | FN0658 |
| 01.04~ | 1600 | F16D3 / LXT | NF19 | RN1324V | PN0374 | RN1391 | PN0376FN12001PN0442 | FN0658 |
| 01.04~01.08 | 1800 | LDA | JD19 | RN1324V | PN0374 | RN1391 | FN12001PN0442PN0376 | FN0658 |
| 11.07~10.13 | 2000 | L34/U20SED | J200 | RN1324V | PN0374 | RN1391 | PN0442 | FN0658 |
