ROTOR DISC » RN2384V

RN2384V

Specification

Type
Vented
Outter Ø
276
Num. of holes
5
Hole Ø:
14.6
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
49.2
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
158
Front/Rear
Front
Structure Material
G3000

Cross Reference

TOYOTA
43512-05060
TOYOTA
43512-20730
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Avensis

10.97~12.03 1800 1ZZ-FE ZZT221L RN2384VRN1111V PN1170PN1362PN1236 DN1238 PN1220FN2347 FN0633
07.00~01.03 2000 1AZ-FSE AZT220L- RN2384V PN1362PN1236 DN1238 PN1220 FN0633
08.99~01.03 2000 1CD-FTV CDT220R RN2384VRN1111V PN1170PN1362PN1236 DN1238 PN1220PN1321FN2347 FN0633
10.97~07.03 2000 3S-FE ST220L RN1111VRN1384VRN2384V PN1236PN1362PN1170 DN1238 PN1321FN2347PN1220
