ROTOR DISC » RN2378

Specification

Type
Solid
Outter Ø
288
Num. of holes
5
Hole Ø:
14.1
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
46
Centering Diameter
70.7
Pitch Circle Ø
115
Drum Ø:
156.2
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GM
0 986 T16 058
GM
13513886
GM
13517854
GM
13517857
GM
13517858
GM
13521008
GM
13544245
GM
13583682
GM
13583685
OPEL
13521008
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.16~08.20 2500 LCV 4X#26 RN2612V PN0694 RN2378 PN52026PN52025
06.16~ 3600 LGX 4Z#79 PN0694 RN2378 PN0886
04.17~11.20 2000 LTG 4Z2 RN2612V PN0694 RN2378 PN0886
09.22~ 1500 LSD 1X#26 RN2377V PN52015 RN2378 PN52022
04.17~08.22 1500 LYX 1X#26 RN2377V PN0628PN0674 RN2378 PN0886
04.17~08.19 1600 LH7 1X#26 RN2377V PN0628PN0674 RN2378 PN0886
04.15~04.18 1500 LFV 1ZD69 US RN2377V PN0628PN0674 RN2378 PN0961
04.18~ 1500 LFV 1ZD69 US RN2377V PN0674PN52015PN0628 RN2378 PN0961PN52022
04.18~ 1500 LFV ZA5C RN2377V PN0628PN52015 RN2378 PN52022PN0886
09.15~ 1500 LFV ZA69 RN2377V PN0674PN0628 RN2378 PN0961PN0886PN52022
04.15~03.18 2000 LTG 1FZ69 RN2377V PN0674PN0628 RN2378 PN0886
01.16~ 2500 LCV 1ZX69 RN2377V PN0628PN0674 RN2378 PN0886
09.22~ 1500 LSD TX#26 RN2377V PN52015 RN2378 PN52022
01.17~08.22 1500 LYX TX#26 RN2377V PN52015PN0674 RN2378 PN52022PN0886
01.17~ 2000 LTG TX#26 RN2612V PN0694PN0674 RN2378 PN0886
03.17~ 1500 B15SFT Z18 RN34003V PN0694PN34002PN0887PN0713 RN2378 PN52014PN0886
03.17~ 1600 B16DTH Z18 RN2612V PN0694PN0887 RN2378 PN0886
03.17~ 2000 D20DTH Z18 RN2612V PN0694 RN2378 PN0886

Exemption from liability: the catalog data is advisory and can be used for reference only
