ROTOR DISC » RN1570

Specification

Type
Solid
Outter Ø
289.5
Num. of holes
5
Disc Thickness (Max)
13
Height
47
Centering Diameter
68
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
155
Disc Thickness (Min)
11
Structure Material
G3000

Cross Reference

NISSAN
43206-4EA0A
NISSAN
43206-4EA0B
RENAULT
43 20 682 31R
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.15~ 1200 H5FT J11R RN1753V PN2804 RN1570 PN2806
12.13~04.21 1200 HRA2DDT J11EER RN1753V PN2804 RN1570 PN2806
08.18~ 1300 HR13DDT J11EEL RN1753V PN2804 RN1570 PN2806
12.13~04.21 1500 K9K J11 RN1753V PN2804 RN1570 PN2806
12.13~04.21 1500 K9K J11E EL RN1753V PN2804 RN1570 PN2806
12.13~04.21 1500 K9K J11E ER RN1753V PN2804 RN1570 PN2806
12.13~04.21 1600 MR16DDT J11E RN1753V PN2804 RN1570 PN2806
12.13~04.21 1600 R9M J11E RN1753V PN2804 RN1570 PN2806
10.15~ 1600 R9M J11R RN1753V PN2804 RN1570 PN2806
12.13~ 2000 MR20DD J11E RN1753V PN2804 RN1570 PN2806
03.14~ 2000 MR20DD J11E GL CHL RN1753V PN2804 RN1570 PN2806
10.15~01.19 2000 MR20DD J11R RN1753V PN2804 RN1570 PN2806
01.19~ 2000 MR20DD J11R RU RN1753V PN2804 RN1570 PN2806
05.20~ 1600 H4M 630 HFMM RN2350V PN43003 RN1570 PN2019
01.15~ 1200 H5F4# HLA3 RN1753V PN2804 RN1570 PN2806
01.15~ 1500 K9K 647 HLA3 RN1753V PN2804 RN1570 PN2806
01.15~ 1600 M5M HLA3 RN1753V PN2804 RN1570 PN2806
01.15~ 1600 R9M HLA3 RN1753V PN2804 RN1570 PN2806

Exemption from liability: the catalog data is advisory and can be used for reference only
