ROTOR DISC » RN2360V

Specification

Type

Vented

Outter Ø

270

Num. of holes

5

Hole Ø:

12.5

Disc Thickness (Max)

28

Disc Thickness (Min)

26.4

Height

51.5

Centering Diameter

69

Pitch Circle Ø

114.3

Drum Ø:

144.8

Front/Rear

Front

Structure Material

G3000

Cross Reference

MITSUBISHI

4615A074

MITSUBISHI

4615A198

MITSUBISHI

MN102275

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MITSUBISHI » L200

06.06~03.15	2400	4G64	KA5T	RN2360V RN1247V	PN3809	DN1104 DN1375	FN6715 FN6741
05.05~04.15	2500	4D56	KA4T	RN2360V	PN3809	DN1375	FN6715

MITSUBISHI » Triton

01.15~	2400	4G64	KJ4T	RN2360V	PN3809	DN1375	FN6706
01.15~	2500	4D56	KJ3T	RN2360V	PN3809	DN1375	FN6706
01.15~	2500	4D56	KL3T	RN2360V	PN3809	DN1104	FN6741
